Technical Specification
NOMINAL BATTERY VOLTAGE
10 to 16 V
MAX. INPUT CURRENT AT 10.5 V RESP. 21 V AND PNOM
67 A
FREQUENCY (MHZ)
Adjustable: 50 Hz or 60 Hz (+/- 0,05%)
WAVE SHAPE
Sinus, total harmonic distortion < 3%
NOMINAL POWER
Continuous at cos phi=1, at a maximum inverter temperature of 75°C
PEAK POWER
60 min.105 - 110%
OUTPUT COS PHI (POWER FACTOR)
All types of load are permitted
INPUT POWER IN UPS MODE
180 - 245 V AC, Switch time < 3msec.
AMBIENT TEMPERATURE (°C)
During storage: -30°C to +70°CDuring use: 0°C to +50°C (inverter temp. 75°C)
RELATIVE HUMIDITY
Max. 95 %, condensation-free (all printed circuit boards are coated)
DIMENSIONS (LENGTH X WIDTH X HEIGHT) (MM)
350x285x120
