Technical Specification
MAX. CHARGING CURRENT (A)
45 A
CHARGING CHARACTERISTIC
4-stage
NOMINAL BATTERY VOLTAGE
12-48 V
MAX. VOLTAGE OF SOLAR PANEL
125
MIN. VOLTAGE OF SOLAR PANEL
9
AMBIENT TEMPERATURE (°C)
During storage: -55ºC to +85ºCDuring use: -40°C to +45°C
RELATIVE HUMIDITY
Max. 95%, condensation-free(p.c.b. is coated)
DIMENSIONS (LENGTH X WIDTH X HEIGHT) (MM)
266 x 127 x 75
